Digital Vickers Hardness Tester NOVOTEST TB-V-50


Digital Vickers Hardness Tester NOVOTEST TB-V-50 implements direct Vickers method of hardness testing in accordance with ISO 6507-2 and ASTM E92.


The instrument allows to measure hardness value of small and thin samples made from steels, non-ferrous metal,  with heat treated layer, carbonized layer, hardened hard layers, superficial coating, small and thin shaped components. Vickers hardness tester is suitable for application in scientific research institutes, metrological institutes, industrial enterprises, etc.


Digital Vickers Hardness Tester NOVOTEST TB-V-50 is modern and high-tech instrument with small test loads (up to 50 kgf), which is equipped by manual turret and analog microscope with automatic data input. The unit is highly reliable, has many operational functions, and is very easy to operate.

The instrument has high-precision optical measuring system and photoelectric sensor. Using keyboard the device allows user to select the testing method; choose hardness scales (HV or HK); set the dwell time; set the intensity of the light source; save the results of measuring in the internal device storage; set time, date  operator id, etc.

All testing data such as: testing method; testing force value; testing indentation length; hardness value; dwell time of testing load; numbers of measurement can be displayed on its large LCD screen.

PC connection and data (measurement results) transfer available via RS232 interface. Also, all the information can be printed via built-in printer.


  • Testing force application method – automatic loading and unloading
  • Accurate measurement system of imprint
  • Large LCD display
  • Connection with PC through RS232 interface
  • Built-in printer


IndenterVickers: four-sided diamond pyramid (136 °)
  • HV
  • HK
Conversion scales
  • HRA
  • HRB
  • HRC
  • HRD
  • HRF
  • HV
  • HK
  • HBW
  • HR15N
  • HR30N
  • HR45N
  • HR15T
  • HR30T
  • HR45T
Testing load
  • 1.0Kgf (9.8N)
  • 2.0Kgf (19.6N)
  • 2.5Kgf (24.5N)
  • 3.0Kgf (29.4N)
  • 5.0Kgf (49.0N)
  • 10Kgf (98.0N)
  • 30Kgf (294N)
  • 50Kgf (490N)
Measuring time5~60 sec
Testing materials
  • Carburized layer, ceramic, steel, non-ferrous metals
  • Sheet, metal foil, plating, fine specimen, surface hardened layers
  • Coatings, nitride layer, the gradient measurement of carburized layer and hardened layer
  • Thin and small objects
Hardness range8 HV(0.3) ~ 2500 HV(10)
StandardsISO 6507-2, ASTM E92
Max height of test sample160 mm(can be produced another model up to 200 mm)
Max depth of test sample135 mm
Microscope zoom
  • For the measurement – 200X
  • For the observation – 100X
Min. graduation value of the testing drum wheel, μm0.0625
Data output
  • LCD display
  • Built-in printer
  • RS-232 interface
Recommended operating conditions
  • Air temperature: 0…+40 °С
  • Air pressure: 94 – 106.7 kPa
  • Humidity: up to 65%
Net weight63 kg
Gross weight73 kg
Package dimensions760*380*750 mm (L*W*H)

Available Option

  • CCD measuring system and data processing PC software
  • Indenters
  • Manual XY test table
  • Digital XY test table
  • Auto XY test table (controlled from PC)
  • Auto turret (controlled from PC)
  • Standard hardness test blocks
  • Weight
  • 10X micrometer eyepiece
  • 10X digital measuring eyepiece
  • Large testing table
  • Medium testing table
  • V-shaped testing table
  • Bolt adjustor
  • Other kinds of power supply
  • Power cable
  • Fuse
  • Max height of test sample up to 200mm

Standard Packages

  • Vickers Hardness Tester NOVOTEST TB-V-10
  • Vickers: four-sided diamond pyramid (136 °)
  • Weight (3 pcs)
  • 10X micrometer eyepiece
  • 10X digital measuring eyepiece
  • Large testing table
  • Medium testing table
  • V-shaped testing table
  • Standard Vickers hardness test blocks (2pcs.)
  • Leveling instrument
  • Bolt adjustor (4 pcs.)
  • Power cable
  • Fuse (2 pcs.)
  • Operating manual
  • Calibration certificate
  • Transportation box
