Portable Vibration Tester TIME®7212

TIME®7212 portable vibration tester can quickly measure vibration of rotating machines like motor, compressor, bearing and others.

Description

TIME®7212 portable vibration tester can quickly measure vibration of rotating machines like motor, compressor, bearing and others. It is suited for on-site flaw detection.

Features

● Fast flaw detection of motor, electric fan, pump, compressor and machine tools

● Convenient shortcut key combinations for calibration mode

● Memory of 100 groups data

● Upper /lower limits pre-setting and sound alarm

● Integrated with printer to print out all the current readings

● With function of time and date setting

● High sensitivity with measuring stability

● Low battery indication



Standard Delivery   Optional Accessory
Main unit 1 Needle groupware
Sensor 1
Magnetic base 1
Charger 1
TIME certificate 1
Warranty card 1
Instruction manual 1



Spesification

Application field

Motor, compressor, bearing and other rotating machine

Measuring parameters

Acceleration(m/s2),Velocity(cm/s),Displacement(mm)

Display resolution

Acceleration

0.1m/s2

Velocity

0.01cm/s

Displacement

0.001mm

Tolerance

≤±5%

Testing range

Acceleration

0.1m/s2 ~ 199.9m/s2(peak value)

Velocity

0.01cm/s-19.99cm/s

Displacement

0.001mm-1.999mm (peak to peak)

Data memory

100 group

Voltage

6V

Charging time

≤132min

Power

Input:220V/AC,50hz Output:12V/DC,600mA

Continuous working time

>16hours

Temperature

0 ~ 40°C

Humidity

90%RH

Dimensions (mm)

230×84×33

Weight (g)

600
