Description
Features
● Three channels(CH1, CH2 and REV) available, the vibration of any two of the three directions (including X axis, Y axis and Z axis)can be tested.
● Five measuring modes: three parameters measuring (AVD mode), dynamic time, domain waveform (TIME mode), dynamic spectrum measurement (FFT mode), data sampling (Sample mode), rotation speed measurement (REV mode).
● The peak value of acceleration, velocity and peak to peak value of displacement are measured.
● Preset the filter’s cut-off frequency of pass band, frequency up to 100Hz.
● Dynamic display the vibration frequency and waveform in real time.
● Continuous data sampling last for 20 seconds
● Powerful data memory management: up to 50 points’infinite data, the measured data of each point is stored in files, users can review the vibration parameters, waveform, frequency data sampling and rotation speed.
● Connected with printer to print out measured data, waveform and spectrum chart.
● Photoelectric transducer for high accurate rotation speed
● Self-diagnosis for malfunction: Alarm sets off if test results out of warning line
● Safe and reliable long-life Li battery with self-protect equipment
● Color LCD display, auto shutdown and buzz alarming
| Standard Delivery | Optional Accessory | |
| Main unit | 1 | Photoelectric keyphasor transducer |
| Vibration probe TSV-03 | 1 | RS232 cable(for printing) |
| Magnetic base | 1 | TPUP-NH thermal printer |
| Protection sheath | 1 | Needle groupware |
| Power adapter | 1 | |
| USB communication | 1 | |
| SD memory card(2G) | 1 | |
| TIME certificate | 1 | |
| Warranty card | 1 | |
| Instruction manual | 1 |
