| Model |
TO-5000OZ |
| OZONE ANALYZER |
Ultraviolet Suction type Densitometer
RANGE : 0 ~ 10 ppm
PRECISION : 0.01 ppm
UPDATES READING EVERY : 12 sec |
| CATEGORY OZONE RANGE |
0.0 ~ 2.5 ppm (standard)
0 ~ 300 ppm (High concentration : Option) |
| TEST CHAMBER |
Stainless Steel Chamber with 125 Liter Capacity provided with terminal Internal Illumination and large Inspection
500 x 500 x 500 mm |
| TEMP. RANGE |
Ambient temp. +10 ~ 90ºC -40ºC (Low temp option) |
| TEMP. CONTROL |
Digital P.I.D Control |
| OVEN AIR VELOCITY |
0.6 m/s |
| AIR FLOW |
10 m³/h |
| ACCESSORIES INCLUDED |
Power cable, Aluminum Static Ozone grip (5EA) |
| POWER (AC 220V, 60Hz) |
1.4KW |
| DIMENSIONS |
1.100 x 650 x 1.530 mm |
| WEIGHT |
Approx. 150 kg |
