Description
As a portable rebound hardness tester, TIME®5302 (TH140) can accurately perform standard hardness testing for all metallic materials. Moreover, it can work with optional dataview software for data analysis on PC.
Portable Hardness Tester TIME®5302
As a portable rebound hardness tester, TIME®5302 (TH140) can accurately perform standard hardness testing for all metallic materials.
Spesification
|
Hardness scale |
HL, HB, HRA, HRB, HRC, HV, HS |
|||
|
Memory |
group (impact times:32-1) |
|||
|
Measuring range |
(170-960)HLD (17.9-69.5)HRC |
|||
|
Tolerance |
±6HLD(when HLD=760±30) |
|||
|
Measuring direction |
360° |
|||
|
Tensile strength U.T.S range |
374～2652MPa |
|||
|
Standard impact device |
D |
|||
|
Optional impact device |
DC/D+15/G/C/DL |
|||
|
Min. Radius of workpiece (convex/concave) |
Rmin=50mm (with special support ring Rmin=10mm) |
|||
|
Max. workpiece hardness |
DC/DL |
D+15 |
C |
G |
|
940HV |
940HV |
1000HV |
650HB |
|
|
Min. Workpiece weight Measure directly Need support firmly Need coupling tightly |
>5kg |
>5kg |
>1.5kg |
>15kg |
|
2～5kg |
2～5kg |
0.5～1.5kg |
5～15kg |
|
|
0.05～2kg |
0.05～2kg |
0.02～0.5kg |
0.5～5kg |
|
|
Min. Workpiece thickness |
5mm |
5mm |
1mm |
10mm |
|
Min. thickness of hardened layers |
≥0.8mm |
≥0.8mm |
≥0.2mm |
≥1.2mm |
|
Power |
Rechargeable NiMH battery, 5x1.2V 600mAh |
|||
|
Continuous working time |
About 50h (without printing and backlight) |
|||
|
Charging time |
2-3.5 hour |
|||
|
Operating temperature |
0℃～40℃ |
|||
|
Humidity |
90% |
|||
|
Dimensions (mm) |
268×86×50 |
|||
|
Weight (g) |
530( including impact device and printer) |
|||
