AQMS-650 Ammonia Analyzer

Description

FPI AQMS-650 measures NH3 in the ambient air, which delivers a stable and precise value. It adopts chemiluminescence technology with an external converter that can combine its use with AQMS-600 measuring NOx; during the measurement, NH3 will be converted into NO by oxidation. And it also comes with its own developed software. The remote PC software allows for a remote connection with a virtual interface and data downloading capability to operate the software.

Features

  • Independent measurement of NOx and NH3;
  • High efficiency external converter;
  • Various outputs include ethernet and RS232;
  • Continuous system diagnosis with alarm;
  • User friendly interface with large screen;
  • Less spare costs,accessories and maintenance requirement;
  • Large data storage capacity;
  • Low power demand of lasted model cause less power consumption.

Specification

Principle
Chemiluminescence
Measured Gas
NH3 in ambient
Range
Min: 0~500ppb Max: 0~2ppm
Lower Detectable Limit
<0.4ppb or 0.5 % of reading
Linearity
<1%F.S.
Response Time
<300 second
Output
RS232, RS485, Ethernet
Operating Temperature
-5~55°C
Power Requirement
(220±10)V AC,(50±10%)HZ
Dimension
178(H)x432(W)x604(D)mm
