Clutch Pack Durability Testing Machine – TO-D101

Features

  • The tester is a high performance device designed to test the clutch durability by implementing a high response speed and adopting the hydraulic valve is a device capable of high-speed test.
  • Controlled by computer and can be a variety of tests to reference the various waveforms. Feedback Control method in a precise static tests, dynamic tests are available, and the user of the computer-controlled Safety  and ease of use, precision, designed to increase durability.

Spesification

Test Chamber Material : SUS304
Temp. Range RT ~ 120°C
Tem. Accuracy ± 2 at 120°C
Pressure Capacity 50 bar
Control Type Hydraulic Servo Valve (Moog)
Test Speed Max 5 Hz
Cooling System Water Cooling System
Motor Hydraulic Pump
Leak Flow Measurement 1 ~ 300 cc
Safety Device Emergency Stop, Limit(Pressure, Over Temp.)
Main Power 380 V 3 p
Weight About 3 ton
