Miniature S-Beam Load Cell

Category: Tags: , , , ,

Description

Applied Measurements DBBSMM miniature S-Beam load cell (or Z-Beam load cell) is suitable for use in tension and compression and lends itself to both force and load measurement applications where the space to mount a standard size load cell is not available.

All of our miniature S-Beam load cells offer high accuracy of better than ±0.03% of their rated capacity and can be optionally gel-filled to provide a waterproof device suitable for applications such as wave tank monitoring.

Rod end bearings and load buttons are available (see gallery images) to provide optimum loading conditions.

If you require a miniature S-Beam load cell with a capacity greater than 50kg, Applied Measurements can manufacture special versions of the DBBSMM with measuring ranges of 100kg, 150kg, 200kg and upwards on request.  Please contact your Applied Measurements expert sales team using the form in the sidebar to discuss your miniature s-beam load cell requirement in detail.

Product Dimensions (mm)

DBBSM Outline

CAPACITY (kgf)
H
L
W
W1
G
G1
Threads T
1, 2, 5, 10, 25, 50
35
24
12
16
17.5
6
M6x1

Wiring Details

WireDesignation
Red+ve excitation
Blue-ve excitation
Green+ve signal (tension)
Yellow-ve signal
ScreenTo ground – not connected to load cell body



Features

  • Capacities: 0-1kg up to 0-50kg
  • Output: 2mV/V nominal
  • Accuracy: <±0.03%/RC
  • Only 35mm High
  • IP51 Environment Protection
  • Custom Versions Available

Spesification

Rated Capacity (RC)kgf0-1, 0-2, 0-5, 0-10, 0-25, 0-50
Operating ModesTension/Compression / Tension & Compression
Sensitivity (RO)mV/V2.0 nominal
Zero Balance/Offset±%/Rated Output<1.0
Zero Return after 30 mins±%/Applied Load<0.03
Output Symmetry (tension vs. compression)±%/Rated Output<0.10
Non-Linearity±%/Rated Output<0.03
Hysteresis% / Rated Output<0.02
Output Symmetry±%/Rated Output<0.10
Repeatability±%/Rated Output<0.02
Temperature Effect on Zero±%/Rated Output/˚C<0.005
Temperature Effect on Sensitivity±%/Applied Load/˚C<0.005
Input ResistanceOhms375-420 nominal
Output ResistanceOhms340-360 nominal
Insulation ResistanceMegohms>5000 @ 50Vdc
Excitation VoltageVolts AC or DC10 recommended (2-15 acceptable)
Operating Temperature Range˚C-20 to +80
Compensated Temperature Range˚C0 to +70
Storage Temperature Range˚C-20 to +80
Safe Overload% of Rated Capacity150
Ultimate Overload% of Rated Capacity200
Maximum Safe Side Load% of Rated Capacity30
Deflection @ Rated Capacitymm (nominal)1kg = 0.50, 2kg = 0.30, 5kg = 0.26, 10kg = 0.19, 25kg = 0.12, 50kg = 0.08
Fundamental Resonant Frequency*Hz1kg = 200, 2kg = 300, 5kg = 600, 10kg = 950, 25kg = 1900, 50kg = 3000
IP Rating (Environmental Protection)IP51 (IP67 optional)
Weight (excluding cable)grams25
Fatigue Life108 cycles typical (109 cycles on fatigue-rated version)
Cable Length (as standard)metres2
Cable Type4-core screened, PVC sheath, Ø3.5
Construction MaterialAluminium Alloy
Resolution1 part in 250,000 (with appropriate instrumentation)
