VERZUS 750U

Description

This closed loop universal hardness tester is constructed around a rock solid C-frame.

Optical automatic image evaluation combined with intuitive operator software avoids operator influence on the test results. Ideal for smaller workshops, educational purposes and for those who want to be versatile in hardness measurement with a larger scale of automation.

Highlights

Scales: Rockwell, Superficial Rockwell, Brinell, Vickers, Knoop, Carbon, HVT, HBT.
Test Forces: 1kgf – 250kgf.
Camera: 5 Megapixels
Objectives: 2.5X, 5X, 10X
Load App. System: Fully automatic, Load cell, closed loop, force feedback.
Control: Fully integrated Windows Controller, SSD hard disk, Windows 10 operated, IMPRESSIONS™ advanced workflow software, includes automatic measurement, keyboard & mouse.
Display: 8.5” industrial touch screen.
Software: Multi USB, CSV files, single readings, reports, printer.
Illumination: Adjustable LED; ring light for dark field illumination (opt.)
Spindle: Manual or motorized. Clamp to protect indenter and fix workpiece to anvil or stage.
Workpiece Acc.: 315mm (H) X 200mm (D).
Anvils: Anvils, stages, accessories as per detailed catalogue.
