| ROLL |
Roll Interval control (digital type) |
| Roll Gap control : Digital type(0.001~10mm adjustable) |
| Roll interring pressure : Max 300kg |
| Roll Surface & Roughness : 50nm |
| Hearing Type |
Temp.Range : RT ~ 350°C ±5°C |
| Heater type : Cartridge Heater |
| Roll Temp (individual control) |
| Rotational Ratio |
Rotational Ratio : Under the same rotation speed |
| Rotational Speed : -~40 RPM |
| Servo Motor |
| Speed Control : Digital Type |
| Driving System |
Pressure part : AC Servo Motor (100 W) |
| Roll driving part - AC Servo Motor (2 kW) |
| LM Unit |
| Power |
AC 220V 3-P 60Hz / 20 kW |
